ED-SBC3300 Series

Home > Products > SBC

ED-SBC3300 Series

A fanless Mini-ITX industrial single board computer based on the Raspberry Pi CM5

Key Featured
  • Broadcom BCM2712 Quad-core Cortex-A76 (2.4GHz), 8GB LPDDR4 RAM, 64GB eMMC Storage
  • Supports Micro SD and mSATA SSD Expansion
  • 2 x Gigabit Eth, 2 x USB 3.0, 5 x USB 2.0, 2 x RS485, 7x RS232
  • 1 x HDMI, 1 x LVDS Dual Display, Supports 4K@60Hz
  • Optional Wi-Fi, Bluetooth, and 4G LTE Wireless Connectivity
  • 9V-36V Wide Voltage Input, PoE Support, -25°C to 50°C Operating Temperature
Online Docs

Product Positioning

A high-performance Mini-ITX industrial motherboard for automation and edge computing, built on Raspberry Pi CM5 architecture. Designed for smart factories, digital signage, and equipment control, it combines multi-protocol I/O, dual-display outputs, and extreme environmental resilience into a compact, fanless computing solution.

Core Advantages

ModuleHighlightsKey Specifications/Technologies
High-Performance ComputePower-intensive edge analytics and control- Quad-core Cortex-A76@2.4GHz (BCM2712)
- 8GB LPDDR4 RAM + 64GB eMMC- mSATA SSD expansion (up to 1TB)
Industrial I/O DensityDirect connectivity for legacy and modern devices- Dual Gigabit Ethernet (PoE support)
- 7× RS232 + 2× RS485
- 5× USB 2.0 + 2× USB 3.0 (5Gbps)
Dual-Display FlexibilityMulti-modal visualization for HMI and monitoring- HDMI 4K@60Hz + LVDS touchscreen (dual independent displays)
- Adjustable LVDS brightness/voltage (12-21.5" panels)
Military-Grade ResilienceUnmatched reliability in harsh environments- -25°C~50°C operating range (surpasses industrial PC standards)
- 9-36V DC wide voltage input (reverse polarity protection)
- Fanless design (IP65 optional)
Scalable ConnectivityWireless and storage expansion tailored to needs- 4G LTE multi-band (global variants) + Wi-Fi 5/Bluetooth 5.0
- Micro SD slot for field data logging

Differentiation

✅ Industrial I/O Mastery: 7× RS232 + 2× RS485 directly connects PLCs/sensors, eliminating expansion modules.

✅ Dual-Screen Workflows: 4K HDMI for dashboards + LVDS touchscreen for local HMI – cut multi-device costs by 40%.

✅ Wide Voltage & PoE: 9-36V DC input or PoE power adapts to unstable grids, reducing cabling complexity.

✅ Industrial-Grade Cold Start: -25°C cold boot capability outperforms competitors .

Typical Applications

🏭 Smart Production Hub: Sync EtherCAT devices via dual Gigabit Ethernet, aggregate sensor data via RS485, and display real-time analytics on 4K/LVDS screens.

📡 Warehouse Edge Gateway: 4G LTE backhauls AGV telemetry, USB 3.0 connects barcode scanners, PoE simplifies ceiling-mounted deployment.

🖥 Rugged Digital Signage: Drive 4K promotional content via HDMI while embedding LVDS touch panels for interactive kiosks in outdoor/industrial settings.

Known Issues

  • 1: The RS485 function is not available at present. If you need to use RS485, we can manually modify it for you.
  • 2: The read rate of some mSATA SSDs is slow.

HS CODE

HS CODECOO
8471504090CN


System Diagram
sbc2300v-diagram
Specification
System
CPUBroadcom BCM2712, quad core Cortex-A76 (ARM v8) 64-bit SoC @ 2.4GHz
VPUH.265 (HEVC), up to 4Kp60 decode
GPUOpenGL ES 3.1 & Vulkan 1.2
MemoryOptions for 2GB, 4GB, 8GB LPDDR4-4267 SDRAM
StorageOptions for 16GB, 32GB, 64GB eMMC storage
Micro SD card (user storage expansion)
mSATA SSD (optional)
Software
Operating SystemRaspberry Pi OS (Desktop) 32-bit
Raspberry Pi OS (Lite) 32-bit
Raspberry Pi OS (Desktop) 64-bit
Raspberry Pi OS (Lite) 64-bit
Rear I/O
Power1 x DC IN, DC Jack connector (2-Pin 3.5mm pitch phoenix terminal is optional). It supports 9V~36V input.
HDMI1 x HDMI port, type A connector, which is compatibles with HDMI 2.0 standard and supports 4K 60Hz.
COM1 x RS232 port, DB9 male connector, using the 2, 3 and 5 pins, the corresponding signal is defined as RX/TX/GND.
USB 3.02 x USB 3.0 ports, type A connector, support up to 5Gbps.
USB2.0/1000M Ethernet Choose one between 2 x USB 2.0 ports and 1 x 1000M Ethernet port.
  • 2 x USB 2.0 ports, type A connector, which support up to 480Mbps.
  • 1 x adaptive 10/100/1000M ethernet port, RJ45 connector.It can be used to access the network.
Different ports can be selected according to actual application.
  • ED-SBC3310: 2 x USB 2.0
  • ED-SBC3311: 1 x 1000M Ethernet
  • ED-SBC3320: 2 x USB 2.0
  • ED-SBC3321: 1 x 1000M Ethernet
1000M Ethernet1 x adaptive 10/100/1000M ethernet port, RJ45 connector. It can be used to access the network.
LINE OUT (optional)1 x Audio Output, 3.5mm audio jack connector(green), stereo audio output.
Note: Only ED-SBC3320 and ED-SBC3321 contains this interface.
MIC IN (optional)1 x MIC Input, 3.5mm audio jack connector(red), which can connect to microphone.
Note: Only ED-SBC3320 and ED-SBC3321 contains this interface.
SD Card Slot1 x Micro SD card slot, which is used to install SD card for storing user data.
SIM Card Slot1 x Nano SIM card slot, which is used to install SIM card for getting 4G signal.
Expansion I/O
Power Supply1 x power port, 2-Pin 5mm pitch connector, reserving to provide power supply for motherboard. It supports 9V~36V input, the signal is defined as VIN+/GND.
Speaker (optional)1 x PA output, 4-Pin 2.0mm pitch WTB connector, dual channel stereo audio output. It can be extended to connect two 4Ω 3W stereo speakers, these pins are defined as R+/R-/L+/L-.
Note: Only ED-SBC3320 and ED-SBC3321 contains this interface.
USB 2.03 x USB 2.0 ports or 5 x USB 2.0 ports, different numbers of USB 2.0 ports can be selected according to actual application.
  • ED-SBC3310 and ED-SBC3320: 3 x USB 2.0 ports (include USB1 and USB3)
  • ED-SBC3311 and ED-SBC3321: 5 x USB 2.0 ports (include USB1, USB2 and USB3)
  • USB1, USB2 and USB3 are the silkscreens of the USB 2.0 ports on the motherboard, corresponding to J19, J20 and J21. The ports and functions are defined as follows:
    • USB1 and USB2 respectively contain 2 x USB 2.0 ports, 2x5(9)-Pin 2.54mm pitch Pin Header. These pins are defined as +5V/+5V/USB1 Date-/USB2 Date-/USB1Date+/USB2Date+/GND/GND/NC.
    • USB3 contains 1 x USB 2.0 port, 5-Pin 2.54mm pitch Pin Header, these pins are defined as +5V/Date-/Date+/GND/NC.
Note: Only ED-SBC3320 and ED-SBC3321 contains this interface.
RS485*12 x RS485, 2x2-Pin 2.54mm pitch Pin Header, which support to expand the RS485 port and the single signal is defined as A/B. A 120R jumper resistor is reserved between A and B of RS485 line. The jumper cap can be inserted to enable the jumper resistor.
6-Pin GPIO1 x GPIO Pin Header, 2x3-Pin 2.54mm pitch Pin Header, which uses to lead out the expansion GPIO ports. User can customize the function according to actual application.The pins are defined as VCC/GND/4xGPIO.
mSATA*21 x mSATA port, Mini PCIe connector, which supports to connect mSATA SSD.
RS232*36 x RS232, 2x5(9)-Pin 2.54mm pitch Pin Header, which support to expand the RS232 ports. The single signal is defined as DCD/RXD/TXD/DTR/GND/DSR/RTS/CTS/R1.
Front Panel (Buttons/Indicators)1 x Front Panel port, 2x5-Pin 2.54mm pitch Pin Header, reserving to connect power button, reset button, HDD indicator and power indicator.
The pins are defined as HDD LED+/HDD LED-/PWR LED+/PWR LED-/RESET-SW/GND/GND/POWER-SW/GND/NC.
Auto-boot after powering on1 x Auto-boot port, 3-Pin 2.54mm pitch Pin Header, which can set whether to enable the auto-boot after powering on by choosing to connect different pins.
The pins and functions are defined as follows:
  • Pin 1-2 (Default): Disable
  • Pin 2-3: Enable
LVDS Display (optional)1 x LVDS Display Port, 2x15-Pin 2.54mm pitch Pin Header. It is reserved to connect LVDS display, and supports up to 1080p 60Hz.
Note: Only ED-SBC3320 and ED-SBC3321 contains this interface.
Voltage Setting of LVDS Display (optional)1 x Voltage Setting port of LVDS display, 2x15-Pin 2.54mm pitch Pin Header. We can set different voltage by choosing to connect different pins, which meets the power supply requirements of various LVDS display.
The pins and functions are defined as follows:
  • Pin 1-2 (Default): +3.3V
  • Pin 3-4: +5V
  • Pin 5-6: +12V
Note: Only ED-SBC3320 and ED-SBC3321 contains this interface.
Enabling Setting of LVDS Display (optional)1 x Enabling Setting port of LVDS display, 2x15-Pin 2.54mm pitch Pin Header. We can open or close the LVDS display by choosing to connect different pins. The pins and functions are defined as follows:
  • Pin 1-2: Open LVDS display
  • Pin 2-3 (Default): Close LVDS display
Note: Only ED-SBC3320 and ED-SBC3321 contains this interface.
Resolution Setting of LVDS Output (optional)1 x Resolution Setting port of LVDS Output, 3x4-Pin 2.0mm pitch Pin Header. We can select screens of different sizes and resolutions by setting the level of pins.
Available screens: 12.1-inch (800x600), 15-inch (1024x768), 15.6-inch (1920x1080), 17-inch (1280x1024) and 21.5-inch (1920x1080).
Note: Only ED-SBC3320 and ED-SBC3321 contains this interface.
Brightness Control of LVDS Display (optional)1 x Brightness Control port of LVDS display, 4-Pin 2.0mm pitch WTB connector. We can adjust brightness of LVDS display by choosing to connect different pins. The pins and functions are defined as follows:
  • Pin 1-2：Brightness increase
  • Pin 2-3：Brightness decrease
  • Pin 2-4：Brightness enable/disable
Note: Only ED-SBC3320 and ED-SBC3321 contains this interface.
Backlight Power (optional)1 x Backlight Power port, 6-Pin 2.0mm pitch WTB connector, which provides 12V power supply, PWM enable and PWM adjustment for backlight of LVDS display.
The pins are defined as +12V/+12V/GND/GND/LVDS_BKL_EN/LVDS_BKL_CTRL.
Note: Only ED-SBC3320 and ED-SBC3321 contains this interface.
Backlight Control (optional)1 x Backlight Control port, 6-Pin 2.0mm pitch WTB connector, which integrates on-board backlight driver circuit, supports enabling and adjustment of backlight brightness.
The pins are defined as Vdc-/Vdc-/Vdc+/Vdc+/Vdc-/Vdc-.
Note: Only ED-SBC3320 and ED-SBC3321 contains this interface.
Expansion Performance
EEPROMSupports 4K byte storage and improves the ease of use of device.
Crypto AuthenticationIt can be matched to realize the required upper layer application and improves the security of device.
RTCEnsure that the system clock is not affected by device power-off.
Note: A CR2032 battery is provided by default in China.
BuzzerA tip or an abnormity can be configurated according to actual application, which realizes the alarm function.
Electrical Characteristics
Input Voltage9V ~ 36V DC
Power Consumption60W (Max)
Mechanical Characteristics
Dimensions170mm x 170mm (W x D)
Weight100g
Wireless
Wi-Fi/Bluetooth (optional)2.4GHz & 5GHz dual-band Wi-Fi and Bluetooth
  • 2.4GHz Wi-Fi: Compatible with IEEE 802.11 b/g/n.
  • 5GHz Wi-Fi: Compatible with IEEE 802.11 a/n/ac.
  • Bluetooth 5.0, compatible with 2402MHz ~ 2480MHz frequency.
4G (optional)Connect with various 4G LTE modules through the Mini PCIe interface.
  • EC20-CE Module (China/India)
    • LTE FDD: B1/B3
    • LTE TDD: B38/B39/B40/B41
    • TDSCDMA: B34/B39
    • WCDMA: B1
    • CDMA 1x/EVDO: BC0
    • GSM: 900/1800MH
    • GPS/GLONASS/BDS/Galileo/QZSS (optional)
  • EC25-AFX Module (North America)
    • LTE FDD: B2/B4/B5/B12/B13/B14/B66/B71
    • LTE TDD
    • WCDMA: B2/B4/B5
    • GSM/EDGE
    • GPS/GLONASS/BDS/Galileo/QZSS
  • EC25-AUX Module (Latin America/Australia/New Zealand)
    • LTE FDD: B1/B2/B3/B4/B5/B7/B8/B28
    • LTE TDD: B40
    • WCDMA: B1/B2/B4/B5/B8
    • GSM/EDGE: B2/B3/B5/B8
    • GPS/GLONASS/BDS/Galileo/QZSS
  • EC25-EUX Module (Europe/Middle East/Africa/Thailand)
    • LTE FDD: B1/B3/B7/B8/B20/B28A
    • LTE TDD: B38/B40/B41
    • WCDMA: B1/B8
    • GSM/EDGE: B3/B8
    • GPS/GLONASS/BDS/Galileo/QZSS
  • EC25-EM Module (Europe/Middle East/Africa/South-East Asia)
    • LTE FDD: B1/B3/B7/B8/B20/B28
    • LTE TDD: B38/B40/B41
    • WCDMA: B1/B5/B8
    • GSM/EDGE: B3/B8
    • GPS/GLONASS/BDS/Galileo/QZSS
Environmental & Regulatory
Operating Temperature-25°C ~ 50°C
Storage Temperature-25°C ~ 60°C
Ambient Humidity5% ~ 95% (non-condensing)
Mechanicals

Unit: mm

image-20240903135117567
Ordering Code
sbc2300c-orderingcode
Docs
Type Title Publish Time
Datasheet ED-SBC3300 Datasheet 2025-01-15
Manual ED-SBC3300 User Manual 2025-01-15
OS ED-SBC3300 Installing OS 2025-01-15
