Home > Products > Industrial Computers

ED-IPC1000

Low-cost Industrial Computer based on Raspberry Pi CM0

Key Featured

  • 1GHz quad-core 64-bit Arm Cortex-A53 processor

  • 512MB SDRAM, options for 8GB/16GB eMMC and 32GB SD card

  • 1 x HDMI, 2 x USB 2.0, 1 x 100M Ethernet

  • Optional 2.4GHz Wi-Fi and Bluetooth

  • USB Type-C for 5V power input

  • Integrated RTC and Watch Dog, CR2032 battery supported for RTC backup power

  • Pre-installed with thermal paste and a passive cooler to provide effective cooling

  • Supports DIN rail mounting

Online Docs

The ED-IPC1000 is equipped with a quad-core 64-bit Arm Cortex-A53 processor running at a main frequency of 1 GHz, delivering balanced and reliable performance.

In terms of storage, it comes with 512MB of SDRAM and offers optional 8GB or 16GB of eMMC storage, flexibly meeting diverse requirements.

It supports 2.4GHz Wi-Fi and Bluetooth 4.2 wireless connectivity, facilitating device networking and data transmission.

For industrial applications, it is also integrated with an RTC (Real-Time Clock) and a Watch Dog function.

A CR2032 battery can be installed as the backup power supply for the RTC, enhancing system reliability.

In addition, the device adopts USB Type-C 5V power input and supports DIN rail mounting, enabling simple power supply and convenient deployment.

Industrial Computer Feature Selection Guide


Function ClassificationIPC2000IPC2100IPC2200IPC2400IPC2500IPC2600IPC3020IPC3100IPC3630CM4 SENCM4 INDCM4 NanoCM4 MEDCM4 IO
CPUCM4✔✔✔✔✔✔---✔✔✔✔✔
CM5-------✔✔-----
Pi 5------✔-------
RAM1/2/4/8GB LPDDR4✔✔✔✔✔✔---✔✔✔✔✔
2/4/8/16GB LPDDR4------✔✔✔-----
Storage8/16/32GB eMMC✔✔✔✔✔✔---✔✔✔✔✔
64GB eMMC-------✔✔-----
Micro SD Card
SSD-✔✔-✔✔✔✔✔✔-✔✔✔
WirelessWi-Fi/BT
4G-✔✔--✔-✔✔✔✔-✔✔
5G----✔---------
Interface1000M Ethernetx 1x 1x 3x 1x 3x 1x 1x 1x 1x 1x 1x 1x 1x 1
100M Ethernet-x 1---x 1-x 1x 1-x 1---
USB 2.0x 1x 2x 2x 1x 2x 2x 2x 2x 2x 2x 2x 1x 1x 2
USB 3.0x 2-x 1x 2--x 2----x 2x 2x 3
RS232-≤ x 2-≤ x 3-≤ x 2x 1≤ x 2≤ x 2x 1x 1---
RS485-≤ x 4-≤ x 4-≤ x 4x 1≤ x 4≤ x 4x 4x 2---
CAN-----≤ x 2--≤ x 2x 1----
HDMIx 1x 1x 1x 1x 1x 1x 2x 1x 1x 2x 2x 2x 2x 2
DSI✔✔✔✔-✔✔✔✔✔✔✔-✔
CSI✔✔✔✔-✔✔✔✔-✔✔-✔
DI/DO-----≤ x 8--≤ x 8-✔---
ADC-----✔----✔---
OtherRTC
Hardware Watch Dog-✔✔-✔✔-✔✔✔✔✔✔✔
High Quality Stereo CODEC-------✔----✔-
Operating-25~60℃✔✔✔✔✔✔✔✔✔✔✔✔--
0 ~ 60°C------------✔✔
MechanicaFanless Design✔✔✔✔✔✔✔✔✔✔✔✔✔-
MountingDIN & Wal!✔✔✔✔-✔-✔✔✔✔✔--
Desktop✔✔✔✔✔✔✔✔✔---✔✔
Power Input（DC）9V~28V✔--✔-----✔----
9V~36V-✔✔-✔✔-✔✔-✔---
7V~18V-----------✔--
5V------✔-----✔-
12V-------------✔


System Diagram
ED-CM0NANO-diagram
Specification
System
CPU1GHz quad-core 64-bit Arm Cortex-A53 processor
VPUH.264/MPEG-4 video decoding, 1080p@30fps
H.264 encoding, 1080p@30fps
GPUOpenGL ES 1.1/2.0 graphics processing
Memory512MB SDRAM
Storage8GB or 16GB eMMC storage available
Optional 32GB Micro SD card (used for system boot when using the CM0Lite module).
Software
Operating System Raspberry Pi OS (Desktop) 64-bit
Raspberry Pi OS (Lite) 64-bit
Raspberry Pi OS (Desktop) 32-bit
Raspberry Pi OS (Lite) 32-bit
Front I/O
Power1 x DC input, USB Type-C connector, supports 5V input.
HDMI1 x HDMI port, Type-A connector, compliant with HDMI 1.3a standard, supports 1080p resolution at 30Hz.
USB 2.02 x USB 2.0 ports, stacked Type-A connector, each supporting a maximum data transfer rate of 480Mbps.
100M Ethernet1 x adaptive 10M/100M ethernet port, RJ45 connector. It can be used to access the network.
Rear I/O
Micro SD Card Slot1 x Micro SD card slot, supports installation of a Micro SD card for system boot.
Note: The Micro SD card slot is only compatible with the CM0Lite.
Side I/O
Antenna Interface1 x Antenna interface, SMA connector, for Wi-Fi/BT antenna
RTC Battery Interface1 x RTC battery interface, supports installation of CR2032 battery via this interface.
DIP Switch1 x DIP switch, supports switching between normal operation mode and flashing mode.
  • LD: Flashing mode
  • RUN: Normal operation mode (default state)
Buttons and Indicators
PWR1 x red power indicator, used to display the device's power on/off status.
ACT1 x green system status indicator, used to monitor the device's operating status.
Reset1 x reset button, recessed design, pressing the button restarts the device.
Expansion Functions
RTCIntegrated RTC function with an RTC battery interface, supporting the installation of a CR2032 battery as RTC backup power.
Watch DogBuilt-in Watch Dog function, enhancing system reliability.​
Electrical Characteristics
Input Voltage5V DC
Power ConsumptionAbout 3.5W
Mechanical Characteristics
Dimensions107.5mm x 94.5mm x 26mm (W x D x H, DIN-rail bracket and antenna are not included)
WeightAbout 320g
InstallationDIN rail mounting
Wireless
Wi-Fi/Bluetooth (optional)Supports 2.4GHz Wi-Fi and Bluetooth, with an external antenna.
  • 2.4GHz Wi-Fi: Compatible with IEEE 802.11 b/g/n
  • Bluetooth 5.0: Compatible frequency band 2402MHz ~ 2480MHz
Environmental & Regulatory
Operating Temperature-20°C ~ 60°C
Storage Temperature-20°C ~ 60°C
Ambient humidity5% ~ 95% (non-condensing)
Mechanicals

Unit: mm

ED-CM0NANO-dimension
Ordering Code

Coding Rules

ipc1000-orderingcode

Ordering Code

ModelDescriptionStocking Level
ED-IPC1000-10008Wi-Fi/BT, 8GB eMMCStandard Stock
ED-IPC1000-10032Wi-Fi/BT, 32GB SD Card (CM0Lite)Standard Stock

TIP

If you require products with other configurations, please contact our sales team separately.​

Docs
Type Title Publish Time
Datasheet ED-IPC1000 Datasheet 2026-01-15
Datasheet bcm2835-peripherals.pdf 2026-01-15
Manual ED-IPC1000 User Manual 2026-01-15
