EtherCAT Analog Input Modules

EtherCAT Analog Input Modules

The EtherCAT analog input module is a high-precision device for industrial automation

Key Featured
  • 4-channel analog input (current/voltage module) or 8-channel analog
  • input (current module)
  • Each channel is equipped with the LED for an operation check
  • Signal current supports 4~20mA/0~20mA
  • Signal voltage supports -5~5V/0~10V/-10~10V
  • 16-bit high-precision analog input
  • Plug-in construction, DIN-rail installation
  • PT removable terminal block for screwless wiring
  • Support cascading up to 32 modules without additional power supply

EtherCAT digital output modules are high-performance devices used in industrial automation control. They provide 4/8/16-channel digital signal outputs, support both transistor (PNP or NPN) and relay outputs, and feature optocoupler isolation and LED status indicators for high reliability and easy maintenance. These modules communicate with the master station via the EtherCAT bus protocol, ensuring high-speed signal transmission and low-latency processing.

Technical Specifications

  • Number of Output Channels: 4, 8, or 16 channels.
  • Output Type: Supports both transistor (PNP or NPN) and relay outputs.
  • Drive Capability:Transistor Output: Single-channel load of 500mA, rated output voltage of 24V DC (±25%).Relay Output: Supports 230V AC or 30V DC, suitable for resistive, inductive, and lamp loads.
  • Power Consumption:Transistor Output: 66mA for PNP type, 19mA for NPN type.Relay Output: 45mA.
  • Isolation Voltage: AC 500V, optocoupler isolation.
  • Dimensions: 100mm x 67.6mm x 14.8mm.
  • Weight: Approximately 51g.
  • Wiring Specifications: 0.2mm² to 1.5mm², screwless wiring method.
  • Installation Method: Rail mounting.

Features

  • High Reliability: Optocoupler isolation ensures stable signal transmission and reduces electromagnetic interference.
  • LED Status Indicators: Each channel has an independent LED indicator light, facilitating on-site debugging and fault diagnosis.
  • Plug-in Structure: Supports rail mounting, making installation and maintenance simple.
  • Cascading Function: Up to 32 modules can be cascaded without additional power supplies, simplifying system wiring.
  • Strong Compatibility: Compatible with CODESYS EtherCAT master stations, suitable for various industrial automation scenarios.

Application Scenarios

EtherCAT digital output modules are widely used in various industrial automation scenarios, including but not limited to:

  • Production Line Automation: Used to control various actuators on the production line, such as solenoid valves and relays, to achieve automated control.
  • Robot Control: In robot control systems, used to control the movements of robots, achieving precise motion control.
  • Smart Manufacturing Systems: Used to connect various intelligent devices, enabling real-time data collection and processing, supporting the efficient operation of smart manufacturing.

Ordering Information

If you are interested in EtherCAT digital output modules, consider the following ordering codes:

  • ED-EIO4YR: 4-channel relay output module.
  • ED-EIO8YP: 8-channel digital output module, PNP type.
  • ED-EIO8YN: 8-channel digital output module, NPN type.
  • ED-EIO16YP: 16-channel digital output module, PNP type.
  • ED-EIO16YN: 16-channel digital output module, NPN type.

Installation and Maintenance

Installing EtherCAT digital output modules is very simple. Just align the notch on the back of the module with the DIN rail and push it in along the arrow direction to fix it on the DIN rail. To remove the module, simply hold the module's latch and pull it out along the arrow direction. Before installation and removal, ensure that the device's power is turned off to avoid damaging the module.

EtherCAT digital output modules have a broad application prospect in industrial automation. They not only provide efficient and stable signal output solutions but also perfectly combine with the CODESYS software platform, providing engineers with powerful development tools. Whether in automated production line control or smart manufacturing systems, EtherCAT digital output modules are key devices for achieving efficient industrial automation.

HS CODE

HS CODECOO
8517799000CN


Optional Remote I/O

ModelDescription
ED-EIOBRG-ECEtherCAT Coupler

Optional I/O Modules

Support a variety of I/O modules, the detailed ordering codes are the table below.

ModelDescription
ED-EIO8XP8-channel digital input module (PNP)
ED-EIO8XN8-channel digital input module (NPN)
ED-EIO16XP16-channel digital input module (PNP)
ED-EIO16XN16-channel digital input module (NPN)
ED-EIO8YP8-channel digital output module (PNP)
ED-EIO8YN8-channel digital output module (NPN)
ED-EIO16YP16-channel digital output module (PNP)
ED-EIO16YN16-channel digital output module (NPN)
ED-EIO4YR4-channel digital output module (Relay)
ED-EIO4ADV4-channel analog input module (voltage), -5~5V/0~10V/-10~10V, configurable
ED-EIO4ADA4-channel analog input module (current), 4-20mA/0-20mA, configurable
ED-EIO8ADA8-channel analog input module (current), 4-20mA/0-20mA, configurable
ED-EIO4AD4-channel analog input module (voltage/current mixed), -5~5V/0~10V/-10~10V/4-20mA/0-20mA, configurable
ED-EIO4DAV4-channel analog output module (voltage), -5~5V/0~10V/-10~10V, configurable
ED-EIO4DAA4-channel analog output module (current), 4-20mA/0-20mA, configurable
ED-EIO4RTD4-channel RTD Module
ED-EIO4TC4-channel TC Module
D-EIO2HCD2-channel High Speed Counter Module
ED-EIOPWRPower Expansion Supply Module
ED-EIOTERMBus End Cover


Specification
Input (current module)
Signal Type Current input
Number of input signal channels 4 8
Input Current Range 0~20mA/4~20mA
Current Dissipation 260mA 400mA
Input Filter Configurable
Input Impedance 100Ω
Resolution 16-bit
Precision 0.1%
Overvoltage Protection Support
Isolation Voltage AC500V on field and digital side, no isolation between channels
Input (voltage module)
Signal Type Voltage input
Number of input signal channels 4
Input Voltage Range -5~5V/0~10V/-10~10V
Current Dissipation 260mA
Input Filter Configurable
Input Impedance >500KΩ
Resolution 16-bit
Precision 0.1%
Overvoltage Protection Support
Isolation Voltage AC500V on field and digital side, no isolation between channels
Input (voltage/current mixed module)
Signal Type Voltage/current input
Number of input signal channels 4
Input Range Voltage: -5~5V/0~10V/-10~10V
Current: 0~20mA/4~20mA
Current Dissipation 260mA
Input Filter Configurable
Input Impedance Voltage: >500KΩ
Current: 100Ω
Resolution 16-bit
Precision 0.1%
Overvoltage Protection Support
Isolation Voltage AC500V on field and digital side, no isolation between channels
Software
FieldbusEtherCAT
EtherCAT Master Software PlatformCODESYS
Mechanical Characteristics
Dimensions100mm x 67.6mm x 14.8 mm
WeightAbout 51g
Wiring Specifications0.2mm² ~ 1.5mm²
Wiring MethodScrewless
InstallationDIN-rail installation
Environmental & Regulatory
Operating Temperature-10℃ ~ 55℃
Storage Temperature-20℃ ~ 85℃
Ambient Humidity5% ~ 95% (non-condensing)
Air Pressure≥ 795 hPa (altitude ≤ 2000 m), compliant with IEC 61131-2
Overvoltage Categories I
Protection ClassIP20
CertificationsCE and RoHS
Mechanicals

Unit: mm

4-channel analog input modules:

4ada-4adv-4ad-dimension

8-channel analog input module:

8ada-dimension
Ordering Code
ModelDescription
ED-EIO4ADA4-channel analog input module (current), 4-20mA/0-20mA, configurable
ED-EIO8ADA8-channel analog input module (current), 4-20mA/0-20mA, configurable
ED-EIO4ADV4-channel analog input module (voltage), -5~5V/0~10V/-10~10V, configurable
ED-EIO4AD4-channel analog input module (voltage/current mixed), -5~5V/0~10V/-10~10V/4-20mA/0-20mA, configurable
