Industrial Computers

Search List
CPU
BCM2711 1.5GHz quad-core A72
BCM2712 2.4GHz quad-core A76
RAM
1GB/2GB/4GB/8GB LPDDR4
2GB/4GB/8GB/16GB LPDDR4X
2GB/4GB/8GB LPDDR4X
Storage
8GB/16GB/32GB eMMC
16GB/32GB/64GB eMMC
Micro SD Card
SSD
Wireless
2.4GHz & 5GHz dual-band WiFi
Bluetooth 5.0 / Bluetooth Low Energy (BLE)
4G
5G
Interface
Gigabit Ethernet
100M Ethernet
USB 2.0
USB 3.0
RS232
RS485
CAN
HDMI
DSI
CSI
DI/DO
ADC
Other
RTC, CR1220
Hardware Watch Dog
Operating
-25℃~60℃
Mechanical
Fanless Design
Mounting
Desktop
DIN & Wall
Power Input
5V DC
9V~28V DC
9V~36V DC
ED-IPC2000 Series

ED-IPC2000 is an enhanced industrial computer based on Raspberry Pi CM4, featuring robust heat dissipation, various connectivity options, and designed for reliability in extreme temperatures.

ED-IPC2100 Series

ED-IPC2100 is a high-performance, versatile industrial computer with 4G/LTE, robust I/O options, and wide temperature operation, designed for reliability in harsh environments.

ED-IPC2200 Series

ED-IPC2200 is a versatile, high-performance industrial computer with optional 4G/5G and Wi-Fi capabilities, designed for reliable operation in a wide temperature range and equipped with rich I/O options for diverse industrial applications.

ED-IPC2400 Series

The ED-IPC2400 series is a robust line of industrial computers based on Raspberry Pi CM4, featuring a powerful processor, flexible I/O options, and a wide operating temperature range, ideal for various industrial automation and control applications.

ED-IPC2500 Series

The ED-IPC2500 is a high-performance industrial computer with 5G capability, featuring a powerful quad-core processor, ample I/O options, and a wide operating temperature range for versatile industrial applications.

ED-IPC2600 Series

ED-IPC2600 series is a robust set of industrial computers based on Raspberry Pi CM4, offering various models with different I/O configurations, dual Ethernet ports, isolated serial communication interfaces, and support for advanced control systems through optional CODESYS compatibility.

ED-IPC3020

The ED-IPC3020 is a high-performance, fanless industrial computer with a powerful Broadcom BCM2712 CPU, dual 4K HDMI outputs, and a wide range of I/O options, designed for reliable operation in extreme temperature environments.


ED-IPC3100 Series
  • Rugged, built for industry
  • CM5 platform, Quad-core
  • 1 x Gigabit, 1 x 100M
  • 2x RS232 & 2x RS485
ED-IPC3600 Series
  • Rugged, built for industry
  • CM5 platform, Quad-core
  • 1 x Gigabit, 1 x 100M
  • 2x RS232 & 2x RS485
  • 8x DO & 8x DI & 2x CAN
CM4 Industrial

CM4 Industrial is a versatile and robust embedded computer based on the Raspberry Pi Compute Module 4, offering various RAM and storage options, a wide range of industrial communication interfaces, and support for diverse display and camera functionalities.


CM4 IO Computer

CM4 IO Computer is a compact and versatile industrial computer series based on the Raspberry Pi Compute Module 4, offering a range of RAM and storage options, dual HDMI 4K output, Gigabit Ethernet, USB 2.0 ports, and support for WiFi, Bluetooth, and PCIe expansion.

CM4 Media

CM4 Media is a high-performance multimedia computer based on the Raspberry Pi Compute Module 4, offering 4K video output, powerful processing, extensive connectivity options, and an elegant aluminum alloy case for efficient heat dissipation and system reliability.


CM4 Nano

CM4 Nano is a compact and powerful industrial computer based on the Raspberry Pi Compute Module 4, featuring versatile RAM and storage options, robust wireless communication, and extensive expansion capabilities for reliable operation in a wide range of temperatures.

CM4 Sensing

CM4 Sensing is a versatile industrial IoT and data acquisition computer based on the Raspberry Pi Compute Module 4, featuring robust wireless communication, multiple serial interfaces, and wide temperature operation capabilities.

ED-IPC Series Feature Selection Guide


Function ClassificationIPC2000IPC2100IPC2200IPC2400IPC2500IPC2600IPC3020IPC3100IPC3630
CPU1.5GHz quad-core A72---
2.4GHz quad-core A76------
RAM1/2/4/8GB LPDDR4---
2/4/8/16GB LPDDR4X--------
2/4/8GB LPDDR4X-------
Storage
8/16/32GB eMMC---
16/32/64GB eMMC-------
Micro SD Card
SSD--
Wireless2.4GHz & 5GHz dual-band WiFi
Bluetooth 5.0 / Bluetooth Low Energy (BLE)
4G----
5G--------
Interface1000M Ethernetx 1x 1x 3x 1x 3x 1x 1x 1x 1
100M Ethernet-x 1---x 1-x 1x 1
USB 2.0x 1x 2x 2x 1x 2x 2x 2x 2x 2
USB 3.0x 2-x 1x 2--x 2--
RS232-≤ x 2-≤ x 3-≤ x 2x 1≤ x 2≤ x 2
RS485-≤ x 4-≤ x 4-≤ x 4x 1≤ x 4≤ x 4
CAN-----≤ x 2 --≤ x 2
HDMIx 1x 1x 1x 1x 1x 1x 2x 1x 1
DSI-
CSI-
DI/DO-----≤ x 8--≤ x 8
otherRTC with backup
Hardware Watch Dog---
Operating-25℃~60℃
MechanicaFanless Design
MountingDesktop
DIN & Wall--
Power Input5V DC--------
9V~28V DC-------
9V~36V DC ---



ED-CM4 Industrial Series Feature Selection Guide



Function ClassificationCM4 SensingCM4 IndustrialCM4 NanoCM4 MediaCM4 IO Computer
CPU1.5GHz quad-core A72
2.4GHz quad-core A76-----
RAM1/2/4/8GB LPDDR4
Storage8/16/32GB eMMC
Micro SD Card
SSD-
Wireless2.4GHz & 5GHz dual-band WiFi
Bluetooth 5.0 / Bluetooth Low Energy (BLE)
4G-
InterfaceGigabit Ethernetx 1x 1x 1x 1x 1
100M Ethernet-x 1---
USB 2.0x 2x 2x 1x 1x 2
USB 3.0--x 2x 2x 3
RS232x 1x 1---
RS485x4x2---
CANx1----
HDMIx2x2x2x2x2
DSI-
CSI--
DI/DO----
ADC----
otherRTC, CR1220
Hardware Watch Dog
High Quality Stereo CODEC----
Operating-25℃~60℃--
0 ~ 60°C---
MechanicalFanless Design-
MountingDesktop---
DIN & Wall--
Power InputDC 5V----
DC 9V~28V----
DC 9V~36V----
DC 12V----
DC 7V~18V----
