OpenClaw Mini Box PC Powered by Raspberry Pi
- Plug & Play AI: Pre-installed JishuShell for one-click OpenClaw deployment
- Unleashed Performance: Powered by the Raspberry Pi CM5 for high-speed AI tasks
- Universal Ecosystem: Full compatibility with the Raspberry Pi ecosystem
- Privacy by Design: 100% local deployment ensures your data stays private and secure, away from the cloud.
- Unified Management: Centralized dashboard for real-time monitoring and seamless integration with Skills and MCP tools
- Always-On Reliability: Industrial-grade stability ensures support for 7x24 hours of continuous operation
- Two Fashion Colors: Carefully selected Moonlight Silver and Pink Gold fashionable shells
|  |
| System |
|---|
| CPU | Broadcom BCM2712, quad core Cortex-A76 (ARM v8) 64-bit SoC @ 2.4GHz |
| VPU | H.265 (HEVC), up to 4Kp60 decode |
| GPU | OpenGL ES 3.1 & Vulkan 1.2 |
| Memory | 4GB LPDDR4-4267 SDRAM |
| Storage | 64GB Micro SD Card |
| Software |
|---|
| Operating System | Raspberry Pi OS (Desktop) 64-bit |
| Rear I/O |
|---|
| Power Port | 1 x USB Type-C Port, supports 5V power input. |
| Standard HDMI Port | 1 x Standard HDMI, Type-A Port, compliant with HDMI 2.0, supports 4K 60Hz resolution. |
| Micro HDMI Port | 1 x Micro HDMI Port, compliant with HDMI 2.0, supports 4K 60Hz resolution. |
| Micro SD Card Slot | 1 x Micro SD Card Slot, for installing Micro SD card to boot the system. |
| Side I/O |
|---|
| 1000M Ethernet Port | 1 x Ethernet Port (10/100/1000M Auto-Negotiation), RJ45 Connector, for Ethernet connection. |
| USB 3.0 Port | 2 x USB 3.0 Ports, Type-A, each supports up to 5Gbps data transfer rate. |
| USB 2.0 Port | 1 x USB 2.0 Port, Type-A, supports up to 480Mbps data transfer rate. |
| Audio Port | 1 x Audio Input/Stereo Output, 3.5mm Audio Jack, can be used for microphone input and stereo output.
- When headphone is connected, audio output switches to the headphone.
- When no headphone is connected, audio output switches to the Speaker.
|
| Antenna Connector | 1 x SMA Connector, for connecting Wi-Fi/BT Antenna |
| Button and Indicator |
|---|
| ON/OFF Button | 1 x ON/OFF Button, with Blue LED; for powering the device ON and OFF. |
| Expansion Functions |
|---|
| Speaker | Built-in 2 x 8Ω 0.8W speakers, supporting external audio playback.
Note: When headphone is connected to the audio port, the speaker has no audio output. |
| Electrical Characteristics |
|---|
| Input Voltage | 5V DC
Note: Raspberry Pi 27W USB-C Power Supply is recommended. |
| Power Consumption (Max) | 12W |
| Mechanical Characteristics |
|---|
| Dimension | 100mm x 100mm x 19mm (W x D x H, the antenna is not) |
| Weight | About 247g |
| Available Colors | Moonlight Silver, Rose Gold |
| Installation | Desktop placement |
| Wireless |
|---|
| Wi-Fi/Bluetooth | 2.4GHz & 5GHz dual-band Wi-Fi and Bluetooth with antenna.
- 2.4GHz Wi-Fi: Compatible with IEEE 802.11 b/g/n
- 5GHz Wi-Fi: Compatible with IEEE 802.11 a/n/ac
- The Bluetooth supports 2402MHz ~ 2480MHz frequency
|
| Environmental & Regulatory |
|---|
| Operating Temperature | 0°C ~ 40°C |
| Operating Temperature | 0°C ~ 40°C |
| Ambient humidity | 5% ~ 95% (non-condensing) |
Unit: mm
| Model | Description | Stocking Level |
|---|
| ED-CLAWBOX-504S | Raspberry Pi CM5, Wi-Fi/BT, 4GB DDR + 64GB SD Card, Moonlight Silver Case | Preview |
| ED-CLAWBOX-504P | Raspberry Pi CM5，Wi-Fi/BT, 4GB DDR + 64GB SD Card, Pink Gold Case | Preview |
Raspberry Pi official power supply can be selected as needed.
| Model | Description | Picture |
|---|
| SC1149 | Raspberry Pi 27W USB-C Power Supply White UK |  |
| SC1153 | Raspberry Pi 27W USB-C Power Supply White US |
| SC1154 | Raspberry Pi 27W USB-C Power Supply Black UK |
| SC1155 | Raspberry Pi 27W USB-C Power Supply Black AU |
| SC1157 | Raspberry Pi 27W USB-C Power Supply Black EU |
| SC1407 | Raspberry Pi 27W USB-C Power Supply White EU |
| SC1158 | Raspberry Pi 27W USB-C Power Supply Black US |
- 1 x ED-CLAWBOX Unit
- 1 x 2.4GHz/5GHz Wi-Fi/BT Antenna
