3 Installing Device

The ED-IPC1220 supports DIN rail mounting. A DIN rail bracket is included as standard and pre-installed.

Steps:

  1. Position the side of the device with the rail bracket against the target rail. Hook the retractable buckle of the bracket onto the lower edge of the DIN rail from bottom to top.

​install-device-1

  1. Hold the device and press the buckle firmly upward until the top of the bracket fully snaps onto the upper edge of the DIN rail.

​install-device-2
