7.0-inch Industrial HMI Based on Raspberry Pi 5
- 7.0" TFT, resolution 1024x600, multi-point capacitive touch screen
- Broadcom BCM2712 2.4GHz quad-core 64-bit Arm Cortex-A76 CPU
- Up to 8GB LPDDR4X RAM, 32GB or 64GB SD Card storage
- 1 x Gigabit ethernet port, 2 x USB 3.0, 2 x USB 2.0
- Dual 4Kp60 HDMI display output
- 5V DC power input via USB-C
- 8-megapixel front camera is optional
- Aluminum CNC + sheet metal case, fanless design, providing excellent cooling performance
|  |
| System |
|---|
| CPU | Broadcom BCM2712 2.4GHz quad-core 64-bit Arm Cortex-A76 |
| VPU | 4Kp60 HEVC decoder |
| GPU | OpenGL ES 3.1 & Vulkan 1.0 |
| Memory | 4GB and 8GB LPDDR4X-4267 SDRAM are optional |
| Storage | 32GB and 64GB SD Storage Card are optional |
| software |
|---|
| Operating System | Raspberry Pi OS (Desktop) 32-bit
Raspberry Pi OS (Lite) 32-bit
Raspberry Pi OS (Desktop) 64-bit
Raspberry Pi OS (Lite) 64-bit |
| Front I/O |
|---|
| Camera | Built-in 8-megapixel front camera (optional) |
| Side I/O |
|---|
| USB 2.0 | 2 x USB 2.0 ports, dual layer type A connector, each channel supports up to 480Mbps. |
| USB 3.0 | 2 x USB 3.0 ports, dual layer type A connector, each channel supports up to 5Gbps. |
| 1000M Ethernet | 1 x adaptive 10/100/1000M ethernet port, RJ45 connector. It can be used to access the network. |
| SD Card Slot | 1 x Micro SD card slot, which is used to install SD card. It supports booting the OS fromSD card. |
| HDMI | 2 x HDMI ports, Micro HDMI connector, supporting 4K 60Hz |
| Power | 1 x power in port, USB Type-C connector, supporting 5V/5A DC power input. |
| Internal I/O |
|---|
| PCIe | 1 x PCIe 2.0 port, reserving to connect peripherals. |
| PoE | 1 x PoE port, reserving to connect PoE module. |
| LCD |
|---|
| LCD Size | 7.0" TFT |
| Resolution | 1024 x 600 |
| Colors | 16.7MB |
| Active Area | 154.21mm (H) x 85.92mm (V) |
| Backlight | LED |
| MTBF | >30000h |
| Pixel Pitch | 400cd/m^2 |
| Contrast Ratio | 800:1 |
| Response Time | 30ms |
| Viewing Angle (CR≥10) | 85° (L) / 85° (R) / 85° (U) / 85° (D) |
| Touch Screen |
|---|
| Type | Multi-point Capacitive Touch Screen |
| Transmittance | ≥85％ |
| Connection Method | COF |
| Controller Interface | I2C |
| Driver Support | Linux |
| Multi-touch | 10 points |
| Surface Hardness | 6H |
| Electrical Characteristics |
|---|
| Input Voltage | 5V DC |
| Power Consumption | 25W (Max) |
| Mechanical Characteristics |
|---|
| Dimensions | 188mm x 123mm x 39mm (WxDxH) |
| Weight | About 800g |
| Installation | Embedded front installation |
| Wireless |
|---|
| Wi-Fi | Dual-band 802.11ac Wi-Fi |
| Bluetooth | Bluetooth 5.0 / Bluetooth Low Energy (BLE) |
| Environmental & Regulatory |
|---|
| Operating Temperature | -20°C ~ 60°C |
| Storage Temperature | -25°C ~ 60°C |
| Ambient humidity | 5% ~ 95% (non-condensing) |
| Certifications | FCC
FCC 47 CFR Part 15 Subpart B
CE
EN IEC 62368-1/EN IEC 62311/EN IEC 61000-3-2/EN IEC 61000-3-3
EN 55032/EN 55035
EN 301 489-1/EN 301 489-3/EN 301 489-17/EN 301 489-52
EN 301 328/EN 301 440/EN 301 511/EN 301 908-1/EN 301 908-2 |
Unit: mm
| Model | Description |
|---|
| ED-HMI3010-070C-0000-L | 7.0-inch LCD Touch Screen for Raspberry Pi 5, with metal case. |
| ED-HMI3010-070CC-0000 | 7.0-inch LCD Touch Screen for Raspberry Pi 5, with metal case, camera and Pi5 Cooling Accessary. |
| ED-HMI3010-070C-0032 | 7.0-inch LCD Touch Screen for Raspberry Pi 5, with metal case, 32GB SD card and Pi5 Cooling Accessary. |
| ED-HMI3010-070CC-0064-L | 7.0-inch LCD Touch Screen for Raspberry Pi 5, with metal case, camera and 64GB SD card. |
| NOTE: If you purchase a product model with Raspberry Pi 5, you need select the Pi5 Cooling Accessary. |
You can also choose Raspberry Pi Active Cooler for Raspberry Pi 5 according to actual needs.
| Model | Description | Picture |
|---|
| SC1148 | Raspberry Pi Active Cooler |  |
You can choose a Raspberry Pi Power Adapter according to actual needs.
| Model | Description | Picture |
|---|
| SC1149 | Raspberry Pi 27W USB-C Power Supply White UK |  |
| SC1150 | Raspberry Pi 27W USB-C Power Supply White AU |
| SC1151 | Raspberry Pi 27W USB-C Power Supply White IN |
| SC1152 | Raspberry Pi 27W USB-C Power Supply White EU |
| SC1153 | Raspberry Pi 27W USB-C Power Supply White US |
| SC1154 | Raspberry Pi 27W USB-C Power Supply Black UK |
| SC1155 | Raspberry Pi 27W USB-C Power Supply Black AU |
| SC1156 | Raspberry Pi 27W USB-C Power Supply Black IN |
| SC1157 | Raspberry Pi 27W USB-C Power Supply Black EU |
| SC1158 | Raspberry Pi 27W USB-C Power Supply Black US |
- 1 x ED-HMI3010-070C Unit
- 1 x Mounting Kit (including 4 x buckles, 4xM410 screws and 4xM416 screws)
