3 Booting The Device

This chapter details the specific procedures for connecting cables and powering on the device.

3.1 Connecting Cables

This section describes the procedures for connecting cables to the device.

Preparation:

  • Available functional accessories: Monitor, mouse, keyboard, I/O expansion module, and power adapter.
  • Available functional network connection.
  • Available functional cables: HDMI cable and Ethernet cable.

Schematic diagram of connecting cables:

Please refer to 1.8 Interface for the pin definition of each interface and the specific method of wiring.

pac3100-connect

3.2 Booting The System For The First Time

The ED-PAC3100 has ​no power switch. When connected to power, the system will begin booting.

  • Red PWR indicator: Lights up to indicate the device is receiving power.
  • ​Green ACT indicator: Blinks to signal normal system startup. The ​Raspberry Pi logo​ will then appear in the upper-left corner of the screen.

TIP

Default username is pi, default password is raspberry.

3.2.1 Raspberry Pi OS (Desktop)

If the device is factory-installed with the ​Desktop OS, it will ​boot directly into the desktop interface​ upon startup, as shown in the figure below.

Desktop

3.2.2 Raspberry Pi OS (Lite)

If the device is ​factory-installed with the Lite OS, it will ​automatically log in​ using the default credentials after startup. The figure below indicates that the system has ​booted successfully.

Lite
