2 Installing the Device

The ED-PAC3020 device is designed for desktop placement by default and supports wall mounting with the optional ​ED-ACCBKT-L3020 wall-mount bracket​ from our company.

TIP

The ED-PAC3020 packaging box does not include the ED-ACCBKT-L3020 by default. Users must purchase it separately.

Preparation:

  • Prepared a Phillips-head screwdriver.
  • Obtained the ED-ACCBKT-L3020 wall-mount bracket.

Step:

  1. Use a Phillips screwdriver to unscrew the four M2.5 screws on the side of the ED-IPC3020 counterclockwise.
install-1
  1. Align the left and right brackets of the ED-ACCBKT-L3020 with the screw holes on both sides of the ED-PAC3020, insert the four M2.5*6 screws, and tighten them clockwise with a Phillips screwdriver to secure the ED-ACCBKT-L3020 to the sides of the ED-PAC3020.
install-2
  1. Based on the spacing and diameter of the wall-mounting screw holes of the ED-ACCBKT-L3020 left and right brackets (refer to the diagram below), drill holes in the wall accordingly, then proceed with wall-mounted installation of the device.
  • Unit: mm
  • Tolerance: 0.5-6±0.05, 6-30±0.1, 30-120±0.15
install-3
