3 Installing Device

ED-IPC1200 supports DIN rail mounting. A DIN rail bracket is included as standard and pre-installed.

Steps:

1. Align the side of the device with the pre-installed rail bracket toward the target DIN rail, and hook the upper end of the bracket onto the top edge of the DIN rail.

​

2. Hold the lower end of the bracket and pull it downward in the direction indicated by the arrow until the bracket snaps securely into place on the DIN rail.

​
