2 Installing Components (optional)

This chapter describes how to install optional components.

2.1 Install Antenna

The ED-IPC1100 device supports both 4G and Wi-Fi functionality, and antennas must be installed before using the device.

Preparation:

The corresponding antenna(s) have been obtained from the packaging box. If multiple antennas are included, they can be distinguished by the labels on the antennas.

Steps:

  1. Find the location of antenna port, as indicated in the figure below.
install-antenna
  1. Align the connectors on both sides of the device and the antenna, and turn the antenna clockwise to secure it.

2.2 Install Micro SD Card

If you need to install the Micro SD card while using the product, you can refer to the following instructions.

NOTE

Please turn off the power before inserting or removing the Micro SD card.

Preparation:

  • Micro SD card is ready.
  • The device has been disconnected from power.

Steps:

  1. Use a Phillips screwdriver to turn the three screws on the DIN rail bracket counterclockwise and remove the default DIN rail bracket.
install-1
  1. Find the location of Micro card slot, as indicated in the figure below.
install-sd-2
  1. Insert the Micro SD card into the corresponding card slot with the contact side facing down, and hear a sound to indicate that the installation is completed.
install-sd-3
  1. Install the DIN rail bracket onto the device.

2.3 Install Nano SIM Card

The ED-IPC1100 device includes 4G functionality by default. Before using the 4G feature, a Nano SIM card must be installed.

NOTE

Please turn off the power before inserting or removing the Nano SIM card.

Preparation:

  • Nano SIM card is ready.
  • The device has been disconnected from power.

Steps:

  1. Use a Phillips screwdriver to turn the three screws on the DIN rail bracket counterclockwise and remove the default DIN rail bracket.
install-1
  1. Find the location of Nano SIM card slot, as indicated in the figure below.
  1. Insert the Nano SIM card with the contact side facing down into the corresponding slot. A click sound indicates that the installation is complete.
  1. Install the DIN rail bracket onto the device.
