ED-HMI3020-070C

7.0-inch Industrial HMI Based on Raspberry Pi 5

  • 7.0" TFT, resolution 1024x600, multi-point capacitive touch screen
  • Broadcom BCM2712 2.4GHz quad-core 64-bit Arm Cortex-A76 CPU
  • Up to 8GB LPDDR4X RAM
  • Support Micro SD Card and M.2 NVMe SSD storage expansion
  • 1 x Gigabit ethernet port with optional PoE
  • Optional 8-megapixel front camera
  • 2 x USB 3.0, 2 x USB 2.0, 1 x RS232, 1 x RS485 and 1 x Buzzer
  • Dual 4Kp60 HDMI display output
  • Stereo audio input and output with separately 3.5mm audio jack, built-in speaker
  • 5V DC power input via USB-C, support ON/OFF power button
  • Built-in RTC, support SuperCAP and CR1220 battery backup
  • Aluminum CNC + sheet metal case, fanless design, providing excellent cooling performance
ED-HMI3010-070C-Datasheetdiagram-2024.05.21

Specifications

System
CPUBroadcom BCM2712 2.4GHz quad-core 64-bit Arm Cortex-A76
VPU4Kp60 HEVC decoder
GPUOpenGL ES 3.1 & Vulkan 1.2
Memory4GB and 8GB LPDDR4X-4267 SDRAM are optional
StorageMicro SD Card Slot, supporting to select the 00GB/32GB/64GB SD card
M.2 NVMe SSD, supporting to select the 00GB/128GB/256GB SSD
software
Operating System Raspberry Pi OS(Desktop) 32-bit
Raspberry Pi OS(Lite) 32-bit
Raspberry Pi OS(Desktop) 64-bit
Raspberry Pi OS(Lite) 64-bit
Front I/O
CameraBuilt-in 8-megapixel front camera(optional)
Side I/O
Audio OUT1 x Audio Output(HPO), 3.5mm audio jack connector(green), stereo audio output.
Audio IN1 x Audio Input(LINE IN), 3.5mm audio jack connector(red), supporting stereo audio input.
Speaker1 x PA output, built-in a 4Ω 3W speaker.
RS4851 x RS485 port, 3-Pin 3.5mm pitch phoenix terminals with 120Ω terminal resistor.
The signal is defined as GND/A/B.
RS2321 x RS232 port, 3-Pin 3.5mm pitch phoenix terminals, the signal is defined RS232 as GND/TX/RX.
USB 2.02 x USB 2.0 ports, dual layer type A connector, each channel supports up to 480Mbps.
USB 3.02 x USB 3.0 ports, dual layer type A connector, each channel supports up to 5Gbps.
1000MEthernet1 x adaptive 10/100/1000M ethernet port, RJ45 connector. It can be used to access thenetwork.
PoE can be supported through expansion module.
SD Card Slot1 x Micro SD card slot, which is used to install SD card. It supports booting the OS fromSD card.
HDMI2 x HDMI ports, Micro HDMI connector, supporting 4K 60Hz
Power1 x power in port, USB Type-C connector, supporting 5V/5A DC power input.
Buttons and Indicators
ON/OFF1 x power button, which is used to turn on and turn off the device.
PWR1 x red power indicator, which is used to check the status of device power-on and power-off.
ACT1 x green system indicator, which is used to check the working status of device.
COM1~COM22 x green UART indicators, which is used to check the communication status of UART port.
Internal I/O
M.2 M1 x M.2 M port, M.2 M Key connector, using to connect SSD and other fast peripherals.
It compatibles with M.2 2230, M.2 2242 and M.2 2260, supporting to boot the OS from SSD.
LCD
LCD Size7.0" TFT
Resolution1024 x 600
Colors16.7MB
Active Area154.21mm(H) x 85.92mm(V)
BacklightLED
MTBF>30000h
Pixel Pitch400cd/m^2
Contrast Ratio800:1
Response Time30ms
Viewing Angle (CR≥10)85°(L)/85°(R)/85°(U)/85°(D)
Touch Screen
TypeMulti-point Capacitive Touch Screen
Transmittance≥85％
ConnectionMethodCOF
ControllerInterfaceI2C
Driver SupportLinux
Multi-touch10 points
SurfaceHardness6H
Expansion Performance
RTCRTC with 1F SuperCAP backup, which can ensure that the system clock is not affected bydevice power-off.
We also provide a battery base, and you can buy a CR1220 batterybackup for RTC.
BuzzerA tip or an abnormity can be configurated according to actual application, which realizesthe alarm function.
Electrical Characteristics
Input Voltage5V DC
Power Consumption25W(Max)
Mechanical Characteristics
Dimensions188mm x 123mm x 40.6mm (WxDxH)
WeightAbout 900g
InstallationEmbedded front installation
Wireless
Wi-FiDual-band 802.11ac Wi-Fi
BluetoothBluetooth 5.0 / Bluetooth Low Energy (BLE)
Environmental & Regulatory
Operating Temperature-20°C ~ 60°C
Storage Temperature-25°C ~ 60°C
Ambient humidity5% ~ 95% (non-condensing)
CertificationsFCC
FCC 47 CFR Part 15 Subpart B
CE
EN IEC 62368-1/EN IEC 62311/EN IEC 61000-3-2/EN IEC 61000-3-3
EN 55032/EN 55035
EN 301 489-1/EN 301 489-3/EN 301 489-17/EN 301 489-52
EN 301 328/EN 301 440/EN 301 511/EN 301 908-1/EN 301 908-2

System Diagram

ED-HMI3020-070C-Datasheet-2024.05.21

Dimensions

Unit: mm

ED-HMI3020-070C-Datasheetdimensions-2024.05.21

Ordering Code

ED-HMI3020-070C-Datasheetorderingcode-2024.05.21

Optional Accessory

You can choose a Raspberry Pi Power Adapter according to actual needs.

ModelDescriptionPicture
SC1149Raspberry Pi 27W USB-C Power Supply White UKED-HMI3010-070C-Datasheet2-2024.05.21.png
SC1150Raspberry Pi 27W USB-C Power Supply White AU
SC1151Raspberry Pi 27W USB-C Power Supply White IN
SC1152Raspberry Pi 27W USB-C Power Supply White EU
SC1153Raspberry Pi 27W USB-C Power Supply White US
SC1154Raspberry Pi 27W USB-C Power Supply Black UK
SC1155Raspberry Pi 27W USB-C Power Supply Black AU
SC1156Raspberry Pi 27W USB-C Power Supply Black IN
SC1157Raspberry Pi 27W USB-C Power Supply Black EU
SC1158Raspberry Pi 27W USB-C Power Supply Black US

Packing List

  • 1 x ED-HMI3020-070C Unit
  • 4 x buckles(including 4xM4*8 screws and 4xM4*16 screws)
